Descrizione
PERFORMANCE
Processor: Intel Core i5-12400, 6C (6P + 0E) / 12T, P-core 2.5 / 4.4GHz, 18MB
Graphics: Integrated Intel UHD Graphics 730
Chipset: Intel B660
Memory: 1x 16GB UDIMM DDR4-3200
Memory Slots: Two DDR4 UDIMM slots, dual-channel capable
Max Memory: Up to 64GB DDR4-3200
Storage: 512GB SSD M.2 2280 PCIe 3.0×4 NVMe Opal 2.0
Optane Memory: None
Card Reader: 3-in-1 Card Reader
Optical: DVD±RW
Audio Chip: High Definition (HD) Audio, Realtek ALC222-CG codec
Speakers: 2Wx1
Power Supply: 260W 90%
DESIGN
Keyboard: USB Calliope Keyboard, Black, Italian
Mouse: USB Calliope Mouse, Black
Front Access HDD: None
Optional Bay: None
Expansion Slots:
– One PCIe 4.0 x16, full-height, half-length
– Two PCIe 4.0 x1, full-height, half-length
– Two M.2 slots (one for WLAN, one for SSD)
Case Color: Chassis: Black Bezel: Grey
System Fan: 1x Rear
Stand: None
Carry Handle: None
Dust Filter: None
Form Factor: Tower (13.6L)
Dimensions (WxDxH): 145 x 294 x 340 mm (5.71 x 11.57 x 13.39 inches)
Weight: 5.5 kg (12.1 lbs)
CONNECTIVITY
Ethernet: Intel I219-V, 1x RJ45
WLAN + Bluetooth: None
Front Ports:
– 2x USB 3.2 Gen 1
– 2x USB 3.2 Gen 2
– 1x USB-C 3.2 Gen 1 (support data transfer and 5V @3A charging)
– 1x headphone / microphone combo jack (3.5mm)
– 1x microphone (3.5mm)
Rear Ports:
– 4x USB 2.0
– 1x VGA
– 1x HDMI 1.4b
– 1x DisplayPort 1.4
– 1x serial (9-pin)
– 1x Ethernet (RJ-45)
– 1x headphone (3.5mm)
Monitor Cable: None
SECURITY & PRIVACY
Security Chip: Discrete TPM 2.0, TCG certified
Fingerprint Reader: No fingerprint reader
Physical Locks: Padlock Loop
Kensington Cable Lock: None
Smart Cable Clip: None
Chassis E-Lock: None
Chassis Intrusion Switch: Chassis Intrusion Switch
MANAGEABILITY
System Management: Non-vPro
SERVICE
Base Warranty: 1-year, Depot
Included Upgrade: 1Y Onsite from 1Y Depot WHB (CPN) (5WS1H22627)
CERTIFICATIONS
Green Certifications:
– EPEAT Gold
– EPEAT Silver
– TCO Certified 9.0
– RoHS compliant
– REACH
– WEEE
Other Certifications: TÜV Rheinland Ultra Low Noise
SOFTWARE
Operating System: Windows 11 Pro 64, WE (EN/FR/DE/NL/IT)
Bundled Software: None
